To view the attribute differences of specific models, please click on "Buy Now" to check.
The ZHF series dual-intake centrifugal fan is a type of fan jointly developed by our R&D staff and industry experts from institutions of higher learning, based on the advanced technologies of Germany, the United States, and Italy, among others;
The ZHF series centrifugal fans are equipped with belt drives as standard and are suitable for ventilation and air exchange in supermarkets, hotels, industrial enterprises, chemical fiber, textile, and general buildings;
They are the best choice for air conditioning purification equipment.
|
FAN PARAMETERS |
|
|
Airflow range |
1500-350000 m³/h |
|
Wind pressure range |
450-3200 Pa |
|
Drive mode |
Belt drive |
|
Installation method |
Seat decoration |
|
Impeller form |
Rear curved steel impeller |
The fan adopts steel fully welded structure, which runs smoothly, has small vibrationand excellent aerodynamic performance, and is in a leading position among similarproducts at home and abroad;
The whole series of specifications range from 450 to 1800, with 13 machine models.Volute outlet angles are generally made into three fixed types: (0°, 90° and 180°).
